Alpha and Omega Semiconductor Limited, a designer, developer, and supplier of power devices and modules, announced its AOLV66935, a 100V High Safe Operating Area (SOA) MOSFET in an LFPAK 8x8 package. It's designed as an solution for 48V Hot Swap architectures in AI servers. In addition to its SOA capability, the AOLV66935 Hot Swap MOSFET features very low on-resistance to meet these performance, efficiency and reliability challenges.
LFPAK 8×8 high‑SOA MOSFETs used in 48 V backplanes to control plug‑in transients and protect server power paths.
(Source: Alpha & Omega Semiconductor)
The AOLV66935 utilizes AOS’ 100V AlphaSGT proprietary MOSFET technology that combines the advantages of trench technology for low on-resistance with high SOA capability. AOS has tested and characterized the SOA at 25°C as well at higher operating conditions of 125°C giving system architects the confidence that the device will operate reliably under harsh conditions. Available in AOS’ state-of-the-art packaging, the MOSFET’s LFPAK 8x8 gull-wing constructed package is 60 percent smaller compared to the TO-263 (D2PAK) package. It also features advanced clip technology with a high current rating to provide high inrush current capabilities. In addition, the copper clip and packaging technology used offers low thermal resistance for improved thermal management. The AOLV66935 is manufactured in IATF 16949-certified facilities, and its LFPAK 8x8 packaging is compatible with automated optical inspection (AOI) manufacturing requirements.
Furthermore, the AOLV66935 provides low power loss and reduced heat generation due to its leading low RDS(on) of 1.86 milliohms maximum rating at Vgs=10V. All the advanced features and high current capabilities designed into the AOLV66935 MOSFET deliver the necessary robustness for enhanced thermal cycling in harsh conditions that is now required in the latest AI server applications.
“To be able to perform the 48V hot swap in AI servers requires a MOSFET that excels in high current capability while providing exceptional high SOA robustness and reliability. AOS designed the AOLV66935 High SOA MOSFET packaged in our advanced LFPAK 8x8 specifically to meet these demands. Plus, its exceptional low on-resistance significantly decreases conduction losses so fewer devices in parallel are required allowing designers to meet space limitations,” said Peter H. Wilson, Sr. Director of MOSFET product line at AOS.
Part Number
Package
VDS (V)
VGS (±V)
TJ (°C)
Continuous Drain Current (A)
Pulsed Drain Current (A)
RDS(ON) Max (mOhms) @10V
@25°C
@100°C
@25°C
AOLV66935
LFPAK 8x8
100
20
175
334
236
1336
1.85
