TDK enables 1250 v dc converters with high-voltage common-mode choke

CONVERTER DESIGNS TDK enables 1250 v dc converters with high-voltage common-mode choke

2026-04-17 From TDK 1 min Reading Time

Related Vendors

Rogers Corporation

MERSEN France SB

PCIM

TDK Corporation has presented the B82722V6*B040 series of new compact high-voltage, current-compensated ring-core double chokes. Designed primarily for rated DC voltages of up to 1250 V (630 V AC), these compact common-mode chokes (23 x 15.5 x 24 mm) effectively suppress EMI in next-generation applications. These include power converters, industrial motor drives, and switch-mode power supplies that often deploy SiC and GaN power semiconductors and feature elevated DC bus voltages, where insulation coordination and PCB space are critical.

TDK’s new high‑voltage common‑mode choke enables compact 1250 V DC converter designs with effective EMI suppression.(Source: TDK) — TDK’s new high‑voltage common‑mode choke enables compact 1250 V DC converter designs with effective EMI suppression.
(Source: TDK)

The series covers nominal inductance values ranging from 3.3 mH to 22 mH, with rated currents between 0.85 A and 3.0 A at a rated ambient temperature of +70 °C. Multilayer solid insulation construction and testing with voltages of 3,750 V (line-to-line) ensure robust electrical isolation. Thanks to the special automated winding technique, these chokes feature high resonance frequency characteristics and a typical stray inductance of around 0.6%, helping to suppress symmetrical interference.

The epoxy coating of the ferrite core and the plastic header comply with UL 94 V-0. The design fulfills the latest IEC 60938-2 and IEC/UL 60939-3 safety requirements for EMI chokes and filters. Suitable for wave soldering and offered in a compact vertical design, the B82722V6*B040 series enables engineers to realize 1250 V DC high-voltage architectures without increasing the PCB footprint.

The BCM6135 is a breakthrough bidirectional 800V-to-48V DC-DC converter that enables lighter, smaller and more efficient power delivery networks in electric vehicles. Its compact size can reduce power system volume by nearly 50%. (Source: Vicor)

Main applications

Suppression of common-mode interference

Compact switch-mode applications

Frequency converters

Main features and benefits

Very high voltage rating

High resonance frequency due to special winding technique

Approx. 0.6% stray inductance for symmetrical interference suppression

Space-saving design

Suitable for wave soldering

Design complies with IEC 60938-2 (630 V AC, 50/60 Hz, PIII; 1250 V DC-link, PII)

RoHS-compatible
