Field-plated super barrier rectifier devices from Diodes

AUTOMOTIVE RECTIFIER Field-plated super barrier rectifier devices from Diodes

2026-09-30 From Diodes 1 min Reading Time

Related Vendors

MRS Electronic GmbH & Co. KG

Diotec Semiconductor AG

ROHM Semiconductor GmbH

Diodes Incorporated announced its family of automotive-compliant field-plated Super Barrier Rectifier (SBRFP) products. Serving as drop-in replacements for comparable Schottky and PN junction diodes, the SBRFP devices feature industry-leading ultra-low forward voltage (V_F) and low reverse leakage current (I_R).

Diodes Incorporated introduces field-plated super barrier rectifiers designed to improve efficiency and reliability in automotive power circuits. (symbolic image)(Source: © Natalia - stock.adobe.com) — Diodes Incorporated introduces field-plated super barrier rectifiers designed to improve efficiency and reliability in automotive power circuits. (symbolic image)
(Source: © Natalia - stock.adobe.com)

This combination enables the design of more efficient and reliable DC-DC converters, reverse-polarity protection (RPP), battery charging systems, automotive LED lighting, and transmission control systems.

Unlike conventional Schottky rectifiers, Diodes’ proprietary and patented SBRFP technology employs a metal oxide semiconductor (MOS) manufacturing process that overcomes the limitations of Schottky and PN junction diodes. The SBRFP8A60P5Q delivers the industry’s lowest maximum forward voltage (V_F) of 0.55V at 8A, reducing conduction losses and enabling cooler operation in high-current applications. Meanwhile, the SBRFP2M60P1Q and SBRFP3M60SAFQ provide industry-leading IR leakage performance, with maximum currents of 12µA and 7µA, at 25°C and 125°C. These characteristics help improve efficiency while minimizing the risk of thermal runaway under high-temperature operating conditions.

New DFN‑packaged ultrafast diodes with wettable flanks enable automated inspection and reliable high‑current performance in DC/DC converters and traction inverters. (symbolic image) (Source: © Natalia - stock.adobe.com)

The new devices also offer significantly greater avalanche capability than traditional Schottky rectifiers. Depending on the device, avalanche energy ratings reach up to 145mJ, enabling the rectifiers to withstand surge events, load dumps, and transient conditions commonly encountered in automotive electrical systems. This avalanche capability is five to ten times greater than conventional Schottky rectifiers, improving overall system robustness and reliability.

The SBRFP family is available in various packages, including PowerDI 123 (SBRFP2M60P1Q), PowerDI5 (SBRFP8A60P5Q), and SMAF (SBRFP2M60SAFQ and SBRFP3M60SAFQ). The devices maintain stable operation across a junction temperature range of -55°C to +175°C, making them suitable for harsh automotive environments.
