BODY CONTROL MODULES Downsizing with smart high-performers from Isabellenhütte

2023-10-16 From Codico GmbH 1 min Reading Time

Related Vendors

Rogers Corporation

CISSOID S.A.

DOWA HD Europe GmbH

Due to increasing vehicle complexity, multiple BCMs are often required, which affects installation space, weight and costs. Therefore, BCMs with higher power density and lower energy consumption are used, which can be achieved by using specific shunts.

How to achieve a higher performance with lower energy consumption?(Source: ©James_Thew_stock.adobe.com) — How to achieve a higher performance with lower energy consumption?
(Source: ©James_Thew_stock.adobe.com)

Body Control Modules (BCMs), also known as central control units, are responsible for controlling and monitoring various vehicle functions such as electric door openers, window regulators, tailgate opening and seat adjustment. The currents for controlling the motors and actuators are monitored and regulated by current sensing resistors (shunts). Since the BCMs are located inside the vehicle, the space and temperature requirements are lower compared to engine or transmission control units.

Due to the high load capacity of ISABELLENHÜTTE's resistors and their stability values, shunts with compact dimensions can be used to intelligently control the current flow in motors. This leads to the optimisation of the performance and efficiency of electric motors, DC/DC converters and regulators, allowing Body Control Modules to achieve higher performance while reducing energy consumption.

Kampagnenbild_WEB_PB_Webkon_20231017_1200x675_AdobeStock_50904691 (iuriimotov - adobe.stock.com)

A practical example illustrates this advantage: If the „BRS“ series size 3812 was previously used, it can be replaced by a more than 5 times smaller „FMK“ shunt of size 1206 without affecting the performance requirements. This is especially useful when multiple shunts are used on the board. Reducing the space requirements in the application contributes to the overall optimisation of weight and system costs. For lower initial component tolerance requirements, it is also possible to use shunts with 5 % or 10 % tolerance, providing a further improvement in the cost-benefit ratio.
